High Temperature Repair Agent
Position：Home > Products > Industrial Glue > High Temperature Repair Agent >737, 757, 767 hot patching agent
737 high temperature repair agent
包装规格：双组分，250g/套 ，16套/箱。
Packaging specifications: two component, 250g/ sets, 16 sets of / box.
性能特点
Performance characteristics
☆ 耐高温性能优良；
☆ excellent high temperature performance;
☆ 与金属、陶瓷等材料具有较高的结合强度；
☆ and metal, ceramics and other materials with high bonding strength;
☆ 固化后无收缩。
Non shrink, after curing.
产品用途
Product use
由改性高温树脂和高温固化剂组成的高温修补剂，以陶瓷、金属等填充聚合而成，短期耐温300℃，长期耐温240℃，用于高温工况磨损、划伤、腐蚀、破裂部位的修补和粘接，如蒸汽及热油管路，发动机缸体，造纸烘缸、塑料成型模具修补和粘接等。
By high temperature repair agent modified high temperature resin and curing agent, filled with ceramic, metal and other polymerization, short-term temperature 300 ℃, the long-term temperature 240 ℃, for high temperature wear, corrosion, scratches, broken parts of repair and adhesive, such as steam and hot oil pipeline, the engine cylinder, dryer plastic molding, mold repair and bonding etc..
使用方法
Method of use
1. 表面处理：对待修补或需粘接部位进行粗化处理，再用清洗剂进行清洗。
1 surface treatment: treat the repair or rough treatment for adhesive parts, cleaning and cleaning agent.
2. 配制：按质量比A:B=2:1或体积比A:B=2:1将A、B两组份混合均匀，并在规定操作时限内用完。
2: according to the mass ratio of A:B=2:1 or the volume ratio of A:B=2:1 to A, B two groups were mixed uniformly, and used within the time limit specified in the operation.
3. 涂敷：将混合好的材料逐层涂敷于待修部位，第一层要压实，使之与基材充分浸润。如后序需机械加工，要留出适量加工余量。
3 coating: the mixed material layer coated on the repair site, the first layer to compaction, so that the full invasion and substrate. If the order need mechanical processing, to set aside appropriate machining allowance.
4. 固化：20～25℃固化24小时或20～25℃固化2小时＋80℃2小时后可投入使用，若温度低应采用加热或延长固化时间来促进固化。
4 curing: 20 ~ 25 ℃ curing for 24 hours or 20 ~ 2 hours at 25 ℃ cured + 80 ℃ after 2 hours can be put into use, if the temperature is low heat or extend the curing time should be used to promote the curing.
Performance parameters
| 物理机械性能表 | |||||
| 颜色 | 物理状态 | 密度(g/cm3) |
抗压强度(kg/cm2) GB/1041-79 |
剪切强度(kg/cm2) GB/7124-86 |
弯曲强度(kg/cm2) GB1042-79 |
| 灰 | 半液态 | 1.48 | 853 | 189 | 436 |
| 固化特性表(测试条件：温度20～25℃，相对湿度55) | ||||
|
可操作时限 (min) |
固化时间 |
满负荷运行 前需固化时间 |
工作温度 (℃) |
最高耐受温度 (℃) |
| 40～60 |
常温24h 或 常温2h+80℃2h |
48h | -60～240 | 300 |
Transportation and storage: store in a cool dry place sealed storage, shelf life of 2 years. Transport to avoid inversion, avoid Kepeng, as non dangerous goods transport.
757高温密封剂
757 high-temperature sealant
包装规格：双组分，500g/套 ，16套/箱。
Packaging specifications: two component, 500g/ sets, 16 sets of / box.
性能特点
Performance characteristics
☆ 耐高温性能优良；
☆ excellent high temperature performance;
☆ 与金属、陶瓷等材料具有较高的结合强度；
☆ and metal, ceramics and other materials with high bonding strength;
☆ 固化后无收缩。
Non shrink, after curing.
产品用途
Product use
由改性高温树脂和高温固化剂组成的高温修补剂，以陶瓷、金属、纤维等填充聚合而成，耐过热蒸汽，耐各类酸碱腐蚀、耐油、韧性好、粘接强度高。接触温度最高可达400℃，可长期在350℃温度下工作。适合于各种高温工况下油、水、汽、酸、碱管路法兰面的修补、密封和粘接等。
By high temperature repair agent modified high temperature resin and curing agent, filled with ceramic, metal, fiber polymerization, resistance to superheated steam, all kinds of acid and alkali corrosion resistance, oil resistance, good toughness, high adhesive strength. Contact temperature up to 400 ℃, can work for a long time at 350 ℃. Suitable for all kinds of high temperature of oil, water, steam, acid, alkali pipeline flange surface repair, sealing and bonding etc..
使用方法
Method of use
1. 表面处理：对待修补或需粘接部位进行粗化处理，再用清洗剂进行清洗。
1 surface treatment: treat the repair or rough treatment for adhesive parts, cleaning and cleaning agent.
2. 配制：按质量比A:B=5:1将A、B两组份混合均匀，并在规定操作时限内用完。
2 preparation: at the mass ratio of A:B=5:1 to A, B two groups were mixed uniformly, and used within the time limit specified in the operation.
3. 涂敷：将混合好的材料逐层涂敷于待修部位，第一层要压实，使之与基材充分浸润。如后序需机械加工，要留出适量加工余量。
3 coating: the mixed material layer coated on the repair site, the first layer to compaction, so that the full invasion and substrate. If the order need mechanical processing, to set aside appropriate machining allowance.
4. 固化：20～25℃固化24小时或20～25℃固化2小时＋80℃2小时后可投入使用，若温度低应采用加热或延长固化时间来促进固化。
4 curing: 20 ~ 25 ℃ curing for 24 hours or 20 ~ 2 hours at 25 ℃ cured + 80 ℃ after 2 hours can be put into use, if the temperature is low heat or extend the curing time should be used to promote the curing.
Performance parameters
| 物理机械性能表 | |||||
| 颜色 | 物理状态 | 密度(g/cm3) |
抗压强度(kg/cm2) GB/1041-79 |
剪切强度(kg/cm2) GB/7124-86 |
弯曲强度(kg/cm2) GB1042-79 |
| 灰 | 膏状 | 1.40 | 595 | 92 | 188 |
| 固化特性表(测试条件：温度20～25℃，相对湿度55) | ||||
|
可操作时限 (min) |
固化时间 | 满负荷运行前需固化时间 |
工作温度 (℃) |
最高耐受温度 (℃) |
| 60～90 |
常温24h 或 常温2h+80℃2h |
48h | -60～350 | 400 |
Transportation and storage
阴凉干燥处密闭贮存，保质期2年。运输中避免倒置，避免磕碰，按非危险品运输。
Store in a cool dry place sealed storage, shelf life of 2 years. Transport to avoid inversion, avoid Kepeng, as non dangerous goods transport.
767超高温修补剂
767 super high temperature repair agent
包装规格：双组分，250g/套 ，16套/箱。
Packaging specifications: two component, 250g/ sets, 16 sets of / box.
性能特点
Performance characteristics
☆ 无机材料，耐高温性能优良；
☆ inorganic material, excellent high temperature performance;
☆ 与金属、陶瓷等材料具有一定的结合强度；
☆ and metal, ceramics and other materials with certain strength;
☆ 固化后无收缩。
Non shrink, after curing.
产品用途
Product use
耐温可达1200℃。用于高温下金属、陶瓷缺陷的填补、粘接及高炉内衬、金属溶液测温探头等高温设备的修补。
The temperature can reach 1200 ℃. For metal, high temperature ceramic defect fill, bonding and blast furnace lining, metal solution temperature probe and high temperature equipment repair.
使用方法
Method of use
1. 配制：按质量比A:B=2:1将A、B两组份混合均匀，并在规定操作时限内用完。
1 Preparation: at the mass ratio of A:B=2:1 to A, B two groups were mixed uniformly, and used within the time limit specified in the operation.
2. 涂敷：将混合好的材料填补在缺陷部位并压实。
2 coating: the mixed material fill compaction in the defect area and.
3. 固化：20～25℃固化2h+加温至80℃保温2h+升温至150℃保温2小时+缓慢冷却至室温后可投入使用。
3 curing: curing 20 ~ 25 ℃ 2h+ heated to 80 ℃ for 2h+ at 150 ℃ for 2 hours + slow cooling to room temperature can be put into use.
Performance parameters
| 物理机械性能表 | |||||
| 颜色 | 物理状态 | 密度(g/cm3) |
抗压强度(kg/cm2) GB/1041-79 |
剪切强度(kg/cm2) GB/7124-86 |
弯曲强度(kg/cm2) GB1042-79 |
| 白 | 膏状 | 1.40 | 595 | 92 | 188 |
| 固化特性表(测试条件：温度20～25℃，相对湿度55) | ||
|
可操作时限 (min) |
固化时间 |
工作温度 (℃) |
| 60～90 | 室温2h+80℃2h+150℃2h+缓慢冷却至室温 | -60～1200 |
Transportation and storage
阴凉干燥处密闭贮存，保质期1年。运输中避免倒置，避免磕碰，按非危险品运输。
Store in a cool dry place sealed storage, shelf life of 1 years. Transport to avoid inversion, avoid Kepeng, as non dangerous goods transport.
